ROCKSY portable Vacuum XRF analyzer is a high-performance field analysis instrument that integrates advanced XRF technology with a vacuum system. Specifically designed for precise elemental detection, it can accurately analyze various sample types, including solids and powders, with advantages including low detection limits, high sensitivity, rapid testing speed, and non-destructive analysis.
ROCKSY is equipped with professional intelligent analysis software and a high-capacity data storage system, supporting real-time data visualization analysis and one-click report generation.Widely applied in geological exploration, industrial inspection, environmental monitoring, and other fields, it is the ideal tool for on-site elemental analysis.
One-click intelligent operation
Lightweight and portable
Accurate and reliable quantitative method
Simultaneous multi-element analysis
| Size | 330mm x 230mm x 305mm（L×W×H） |
| Weight | ＜11kg |
| Core Technology | X-ray fluorescence(XRF) |
| Element Range | Na-U |
| Concentration Range | ppm~99.99% |
| Sample Types | Solids, powders, etc. |
| Excitation Source | High-performance micro X-ray tube (W/Ag/Rh target selectable) |
| Tube Voltage | 5~50kV |
| Detector | Large-area SDD detector (Energy resolution ≤125 eV) |
| Filter | 4 auto-switching filters |
| Operating Temp | -20℃～+55℃ |
| Operating Humidity | 40–70% RH (non-condensing) |
| Optional modes | Vacuum mode / Air mode / He purging mode |
